50pcs ESD Magazine Rack PCB Storaged Electrostatic Discharge For Industry Use
Product Details:
| Place of Origin: | CN |
| Brand Name: | Herzesd |
Payment & Shipping Terms:
| Price: | USD 35-50/ set |
|---|
|
Detail Information |
|||
| Features: | Easy To Assemble, Lightweight, Durable | High Temperature Resistance: | 80℃,120℃ And 200℃ Above Are Available |
|---|---|---|---|
| Size: | 460mm*400mm*563mm | Number Of Shelves: | 1 |
| Capacity: | 50pcs PCB Could Be Storaged | Usage: | Electrostatic Discharge |
| Material: | Conductive PP/PPE, Zinc Plated Steel, Aluminum Alloy | Adjust Type: | Screw/ Gear Track |
| High Light: | PCB Storaged ESD Magazine Rack,50pcs ESD Magazine Rack,Electrostatic Discharge Antistatic PCB Rack |
||
Product Description
Product Description:
- Product Name: ESD Magazine Rack
- Compatibility: ESD-Safe Workstations
- Name: ESD Magazine Rack
- Number of Shelves: 1
- Assembly Required: Yes
- Static Dissipation: 10^3-10^9 Ohms
- Special Features: SMT PCB Circulation Storage, Antistatic SMT PCB Loader, ESD PCB Magazine Rack
Size Table:
| Model | Outer size(mm) | PCB plate size(mm) | Base material | Adjust type | Temp. | Slots | Weight (KG) |
| HZ-2601 | 355*315*580 | 355*(80-250) | Plastic | Screw adjust. | 80℃ | 50 | 5 |
| HZ-2602 | 355*315*305 | 355*(80-250) | Plastic | Screw adjust. | 80℃ | 25 | 3.4 |
| HZ-2603 | 355*320*563 | 355* (50-250) | Metal | Screw / gear track | 80℃/120℃/200℃ | 50 | 5 |
| HZ-2604 | 355*320*563 | 355* (50-250) | Plastic | Gear track | 80℃/120℃ | 50 | 4.5 |
| HZ-2605 | 355*320*563 | 355* (50-250) | Metal | Screw / gear track | 80℃/120℃ | 50 | 6.5 |
| HZ-2606 | 355*320*563 | 355* (50-250) | Metal | Gear track | 80℃/120℃ | 50 | 6 |
| HZ-2607 | 460*400*563 | 460*(50-330) | Metal | Screw / gear track | 80℃/120℃/200℃ | 50 | 8 |
| HZ-2608 | 535*460*570 | 535*(50-390) | Metal | Screw / gear track | 80℃/120℃ | 50 | 10.5 |
| HZ-2609 | 535*530*570 | 535*(120-460) | Metal | Screw / gear track | 80℃/120℃ | 50 | 12 |
| HZ-2610 | 630*530*570 | 630*(50-460) | Metal | Screw adjust. | 80℃ | 50 | 13 |
| HZ-2611 | 355*320*560 | 355* (50-250) | Plastic | Chain adjust. | 80℃ | 50 | 6 |
| HZ-2612 | 355*320*560 | 355*(80-250) | Metal | Screw / gear track | 550℃ | 50 | 6.8 |
| HZ-2613 | 400*320*563 | 400*(50-250) | Metal | Screw / gear track | 80℃ | 50 | 6 |
Applications:
Herzesd magazine racks meet the standard dimensions usually found on automated lines. They have a strong injection molded construction with metal reinforcement at the top and bottom. Plus, they have a standardized plate which fits the majority of popular brands on the market.
Technical Parameters:
| Parameter | Value |
|---|---|
| Usage | Electrostatic Discharge |
| Adjust Type | Screw/ Gear Track |
| Options | Please Contact Us For More Sizes |
| Material | Conductive PP/PPE, Zinc Plated Steel, Aluminum Alloy |
| Assembly Required | Yes |
| Package Includes | 1 X Magazine Rack |
| Static Dissipation | 10^3-10^9 Ohms |
| Features | Easy To Assemble, Lightweight, Durable |
| Size | 460mm*400mm*563mm |
| Compatibility | ESD-Safe Workstations |
| ESD PCB Magazine Rack | SMT PCB Circulation Storage, ESD PCB Magazine Rack Box, ESD Protective Magazine Rack |
Customization:
Brand Name: Herzesd
Place of Origin: CN
Static Dissipation: 10^3-10^9 Ohms
Name: ESD Magazine Rack
Usage: Electrostatic Discharge
Options: Please Contact Us For More Sizes
Number of Shelves: 1
Keywords: ESD PCB Magazine Rack, SMT PCB Circulation Storage, Antistatic SMT PCB Loader
Packing and Shipping:
ESD Magazine Rack Packaging and Shipping:
The ESD Magazine Rack will be securely packaged in a heavy-duty box with adequate cushioning material to protect it during transit. It will be shipped using an appropriate shipping method to ensure its safe and timely delivery.
