ESD Vinyl Floor Tile Easy Maintaince PVC Flooring
Product Details:
| Place of Origin: | SH,CN |
| Brand Name: | None |
| Certification: | Rohs, CE |
| Model Number: | HZ-F01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100sqm |
|---|---|
| Price: | 6usd/m2 |
| Packaging Details: | pallet |
| Delivery Time: | 5-7 work days |
| Payment Terms: | T/T, D/P, |
|
Detail Information |
|||
| Color: | Multi Pattern&Color | Thickness: | 2mm/3mm Or 2.5mm |
|---|---|---|---|
| Material: | PVC, Plasticizers, Stabilizers, Etc.. | Surface: | RHPP Treatment |
| Product Name: | Conductive Floor Tiles | Surface Resistance: | 10^4-10^6 Ohm/10^6-10^9 Ohm |
| Usage: | Antistatic,Cleanroom Protection | Feature: | Anti-static,Acid And Alkali Resisitant,Oil Resisitant,waterproof,wearable |
| Length: | 10m,or Customized | ||
| Highlight: | ESD Vinyl Floor Tile,Easy Maintaince ESD Vinyl Floor Tile,Easy Maintaince PVC Flooring |
||
Product Description
Description of Conductive Floor Tiles:
Spec:
Sheet size: 600mm*600mm/900mm*900mm
Roll size: 2m*20m/Roll
Thickness: 2.0mm/3.0mm (2.5mm customized)
System Resitance: 104-106 ohm (Conductive)
Designed to dissipate electric charges when grounded or connected to a lower potential point.
It is categorized based on surface resistivity into conductive and static dissipative types.
PVC flooring features two main characteristics: stain resistance and easy cleaning.
Stain resistance is achieved through seamless interlocking and PUR surface treatment.
Various stains on PVC flooring do not penetrate the floor, preventing dirt residue and odors.
| Item | Standard | Index |
| Size | EN426 | 600*600mm |
| 900*900mm | ||
| Thickness | EN428 | 2.0, 2.5, 3.0mm |
| Weight | EN430 | 2.0mm, 3.8kgs/m3 |
| 2.5mm, 4.8/kgs/m3 | ||
| 3.0mm, 5.8/kgs/m3 | ||
| Surface Rresistance | DIN51953 | 104-106 Ω Conductive |
| ASTMF-1550 or NFPA99 | 106-109 Ω Dissipative | |
| Decay Time | SJ/T10694-2006(VI<100V) | Equal 0.4S |
| Charge Voltage | SJ/T10694-2006(VI<100V) | Equal 70 |
| Fire Resistance | DIN 4102 | B1 |
| Combustion Properties | SJ/T11236-2001(<10s,FV-0) | Equal 0.35s Ifv-0 |
| Amount of anti-wear | SJ/T11236-2001(less than 0.02g/cm3, 110r) | Equal 0.014 |
| Anti-wear Properties | EN660pt2 | Ten-T < 2.0 mm3 |
| Wheel Pressure | EN425 | No influence |
| Residual Concavity | EN433, DIN51955 | 0.03mm(2.0mm) |
| 0.035mm(2.5mm) | ||
| 0.04mm(3mm) | ||
| Dimensional stability | EN434 | Less than 0.1% |
| Color fastness | IDO105BO2 | At least 6 |
| Resistance to chenmicals | DIN423,DIN51958 | offers excellent resistance ask for special sheet |
