3 Layer Anti Fatigue ESD Mat for Standing Workstations

3 Layer Anti Fatigue ESD Mat for Standing Workstations

Product Details:

Place of Origin: China
Brand Name: Shanghai

Payment & Shipping Terms:

Minimum Order Quantity: 10
Price: $13-18
Get Best Price Contact Now

Detail Information

Material: PVC+EVA/EPDM Foam+Rubber Thickness: 10mm-30mm
Volume Resistance: 10e6-10e9 Ohm Max Weight: 100KG
Surface Resistance: 1x10E6-10E9 Ohms Ground Resistance: 109-1010ohm
Size Option 1: 610x910x18mm Size Option 2: 610x450x18mm
Layer Structure: 3 Layers Surface Layer: PVC
Middle Layer: Carbamic Resin Bottom Layer: Conductive Rubber
Color Options: Black & Yellow, All Black, Blue, Gray, Red Anti-fatigue Effect: Better
Model Variants: HZ-950, HZ-930, HZ-418S, HZ-418E, HZ-418B
Highlight:

3 layer ESD mat for workstations

,

anti fatigue ESD rubber mat

,

standing workstation ESD mat

Product Description

3 Layers Anti Fatigue Mat for Standing Workstation
Product Specifications
Attribute Value
Product Name Anti Fatigue Rubber Mat
Material PVC+EVA/EPDM foam+Rubber
Size Customized
Thickness 10mm-30mm
Color Black & yellow; All black; Blue; Gray; Red
Volume Resistance 10e6-10e9 ohm
Recommended Work Condition Weight <100KG
Usage Electronic Workshop
Application Standing Workstation
Feature 3 Layers Structure
Product Description

Our 3-layer anti-fatigue mat features a surface layer of PVC, middle layer of carbamic resin, and bottom layer of conductive rubber. Available in standard sizes (610x910x18mm, 610x450x18mm) with custom sizes available.

Surface resistance: RTT 1x10E6-10E9 ohms. Ideal for electronic components manufacturers and static sensitive areas.

Available Models
Model Size(mm) Material Surface Resistance Ground Resistance Anti-fatigue Effect Note
HZ-950 610x460x15 Good Natural Rubber <107ohm <107ohm Best
HZ-930 610x910x12.5
610x450x12.5
Rubber Material 108-109ohm 108-109ohm Good Low cost design
HZ-418S 610x910x17 2 layers: PVC+ Carbamic resin 108-109ohm 109-1010ohm Better
HZ-418E 610x910x18
610x450x18
3 layers: PVC + Carbamic resin + Conductive rubber 108-109ohm 109-1010ohm Better
HZ-418B 610x910x20 3 layers: PVC + EPDM + Conductive rubber 108-109ohm 109-1010ohm Better Low cost design
Key Features
  • Cushioning: Reduces pressure on feet, legs, and back to alleviate discomfort and fatigue
  • Ergonomic: Promotes proper posture and reduces risk of musculoskeletal disorders
  • Slip-resistant: Prevents slips in wet or oily environments
  • Durable: Withstands heavy use and resists wear and tear
  • Anti-static: Prevents static electricity buildup that can damage electronics
  • Easy to clean: Maintains hygiene and prevents bacterial buildup
  • Customizable: Available in various sizes and shapes to fit specific workspace needs
  • Versatile: Suitable for industrial, commercial, kitchen, salon, and medical settings
Product Images
3 Layers Anti Fatigue Mat for Standing Workstation
Close-up of Anti Fatigue Mat surface
Anti Fatigue Mat in use at workstation
Packaging & Shipping
Packaged Anti Fatigue Mats ready for shipping
Anti Fatigue Mat packaging detail
Stacked Anti Fatigue Mats in warehouse
Shipping container with Anti Fatigue Mats
Company Information

The ESD products manufactured and supplied by Shanghai Herzesd Industrial represent meticulous planning and technological excellence. Our products showcase a fine combination of quality, innovation, and technology, with continuous upgrades to enhance security features for various ESD applications.

Our durable products are built with precision technology by a dedicated team committed to improving machine security and performance.

Shanghai Herzesd Industrial facility
