Adjustable Height ESD PCB Storage Trolley for SMT Circuit Board Handling

The Adjustable Height ESD PCB Storage Trolley is built for SMT and electronics workshops that need to move and store circuit boards safely between stations. Its conductive steel frame carries anti-static ABS-coated rails that hold PCBs upright and apart, so boards travel without touching each other and without building up the static charge that damages fine-pitch components. Because the rail pitch adjusts across a wide range, the same adjustable ESD PCB storage trolley accepts narrow prototype boards and wide production panels without extra tooling. The frame is welded and powder-coated in a conductive finish, then fitted with grounded conductive casters so the whole cart stays tied to the shop floor ground while it is pushed along an aisle. Operators can load, move, and unload a full magazine of boards in a single trip, which cuts handling touches and the associated risk of edge damage and electrostatic discharge.

• Adjustable Rail Spacing: Anti-static rails slide and lock across a wide pitch range, so the SMT circuit board handling rack holds different board widths without dedicated fixtures.
• Conductive Anti-Static Construction: A steel frame with conductive powder coating keeps the whole trolley inside the 10⁴ to 10⁹ ohm window expected for ESD-protected areas.
• ESD-Safe PCB Contact: Anti-static ABS-coated rails cradle each board on soft, non-scratching surfaces that protect copper traces, solder mask, and fine-pitch devices.
• Stable Load Capacity: A welded base and reinforced uprights carry a full magazine of boards up to 300 kg without flexing or tipping during transport.
• Smooth-Rolling Conductive Casters: Four grounded swivel casters, two with brakes, keep the cart grounded and let a single operator steer a fully loaded trolley through tight aisles.
• Space-Saving Vertical Storage: Boards stand on edge in a compact footprint, freeing valuable bench and floor space while keeping boards visible and easy to count.

This SMT circuit board handling rack is specified wherever boards move between machines, benches, and stores. It is commonly used between SMT printers, placement lines, and reflow ovens, at AOI and test stations, and in board stores and kitting areas where a controlled magazine is needed. It also suits electronics repair and RMA benches, laboratories, and any workshop that must keep assemblies static-safe while moving them in volume.

• Between SMT printers, placers, and reflow ovens
• AOI, X-ray, and functional test stations
• PCB stores, kitting, and staging areas
• Electronics repair and RMA benches
• Laboratory and prototype build areas
• Cleanroom and ESD-protected production floors

Each pair of anti-static rails slides and locks on the uprights, so an operator can set the pitch to match a board width in seconds. That lets one adjustable ESD PCB storage trolley serve narrow prototypes and wide production panels alike.

Yes. The conductive steel frame, conductive powder coating, anti-static rails, and grounded casters keep the whole cart inside the 10⁴ to 10⁹ ohm window expected for the SMT circuit board handling rack, so boards stay protected while the trolley rolls along an aisle.

No. The anti-static ABS coating is soft and non-abrasive, so it cradles each board without scratching copper traces, solder mask, or fine-pitch components.

The trolley carries up to 300 kg. Four grounded swivel casters, two of them braked, let a single operator steer a fully loaded cart through tight aisles and lock it in place at the bench.

The minimum order quantity is 10 pieces, and standard orders ship within 15 to 25 days after deposit confirmation. Custom slot counts and sizes are quoted individually.

Each trolley is partly assembled and packed in a foam-lined export carton or on a pallet, with rails and casters protected for container shipping. Every batch is checked for surface resistance, dimensions, adjuster travel, and load stability, and the records are kept on file so a buyer can trace the values of a delivered lot. The product is RoHS compliant and made under ISO 9001 quality management, and third-party inspection before shipment is welcome so your adjustable ESD PCB storage trolley matches the specification you approved.
