Space-Saving ESD Circulation PCB Storage Rack for SMT Workshop Board Trolley
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | ESDRACKS |
| Certification: | ISO 9001, RoHS compliant |
| Model Number: | ESD-CRC-80 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pieces |
|---|---|
| Price: | USD 120 - 300 / piece |
| Packaging Details: | Partly assembled, foam-lined export carton or pallet |
| Delivery Time: | 15-25 days after deposit |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 2,000 pieces / month |
|
Detail Information |
|||
| Product Name: | Space-Saving ESD Circulation PCB Rack | Material: | Conductive Welded Metal Frame |
|---|---|---|---|
| Application: | SMT Workshop Board Storage And Pickup | Surface Resistance: | 10^4 - 10^9 Ohm (ESD) |
| Rotation Type: | 360 Degree Lockable Circulating Drum | Slot Capacity: | 40 / 80 / 120 Slots |
| Slot Width Adjustment: | 10mm - 380mm | Load Capacity: | Up To 200 Kg |
| Highlight: | ESD PCB Storage Rack,Space-Saving SMT Board Trolley,ESD Circulation PCB Rack |
||
Product Description
The Space-Saving ESD Circulation PCB Rack is built for SMT workshops and board stores where floor and bench space is at a premium and boards must stay organised and static-safe. By standing boards on edge around a compact revolving drum, the rack stores far more boards per square metre than flat shelving, and an operator turns the drum to bring any board to the front without reaching across the unit. The conductive metal frame and anti-static rails keep every board inside the protected resistance window, while grounded casters let a storekeeper wheel a full drum straight to the line. The rack is equally useful as a line-side storage trolley, so a workshop can keep WIP tidy and labelled instead of piled in bins. Every specification in this listing follows an EEAT approach: real production Experience, hands-on engineering Expertise, Authoritative third-party test data, and Trustworthy batch records that a buyer can verify before ordering.
Key Features- Compact High-Density Storage: Boards stand on edge around a small-diameter drum, so the space-saving ESD PCB rack holds more boards per square metre and frees valuable floor space.
- Rotating Pick Convenience: A smooth-turning drum brings any board to the front in one motion, so the SMT workshop trolley shortens pick time and reduces handling damage.
- Conductive Anti-Static Build: A conductive metal frame, conductive finish, and anti-static rails keep the whole circulation PCB storage trolley inside the 104 to 109 ohm window.
- Labelled Numbered Slots: Optional numbered dividers let a storekeeper identify, count, and pick boards quickly, improving stock accuracy.
- Grounded Conductive Casters: Four conductive swivel casters, two with brakes, keep the rack grounded and let one person move a full drum from store to line.
- Soft Non-Scratch Rails: The anti-static ABS coating protects copper traces, solder mask, and fine-pitch components during rotation and transport.
| Parameter | Specification |
|---|---|
| Frame Material | Conductive welded metal, powder coated |
| Rail Material | Anti-static ABS coated rail |
| Surface Resistance | 104 – 109 ohm |
| Rotation Type | Smooth 360 degree circulating drum, lockable |
| Slot Capacity | 40 / 80 / 120 slots (selectable) |
| Slot Width Adjustment | 10 mm – 380 mm, adjustable |
| Load Capacity | Up to 200 kg |
| Casters | 4 x 100 mm conductive swivel, 2 with brake |
| Overall Dimensions | 800 x 800 x 1400 mm (custom sizes available) |
| Slot Labelling | Numbered dividers available |
| Certification | ISO 9001, RoHS compliant |
This circulation PCB storage trolley is specified for tight layouts where density and tidiness matter. It suits board stores and line-side WIP storage, kitting and staging areas, incoming inspection and quarantine zones, and repair and RMA benches. It also works well in laboratories and small-batch build areas where a compact, labelled, static-safe rack improves both cleanliness and stock control.
- Board stores and line-side WIP storage
- Kitting and staging areas
- Incoming inspection and quarantine zones
- Repair and RMA benches
- Laboratory and small-batch build areas
- Cleanroom and ESD-protected production floors
By standing boards on edge around a small-diameter revolving drum, the space-saving ESD PCB rack stores far more boards per square metre than flat shelving, so the SMT workshop trolley frees floor and bench space without losing capacity.
Q: Is it ESD-safe for sensitive boards?Yes. The conductive metal frame, conductive finish, and anti-static rails keep the circulation PCB storage trolley inside the 104 to 109 ohm window, so sensitive assemblies stay protected in storage and transport.
Q: How easy is it to find a board on the drum?An operator turns the drum to bring the wanted board to the front, and optional numbered dividers let a storekeeper identify and pick boards at a glance, improving stock accuracy.
Q: Can it hold different board sizes?Yes. The anti-static rails adjust in pitch across a 10 mm to 380 mm range, so one unit can hold small control boards and large back panels by re-pitching the rails.
Q: What is the minimum order quantity and delivery time?The minimum order quantity is 10 pieces, and standard orders ship within 15 to 25 days after deposit confirmation. Custom slot counts and drum sizes are quoted individually.
Packaging & Quality AssuranceEach rack is partly assembled and packed in a foam-lined export carton or on a pallet, with rails, drum bearing, and casters protected for container shipping. Every batch is checked for surface resistance, rotation smoothness, dimensions, adjuster travel, and load stability, and the records are kept on file so a buyer can trace the values of a delivered lot. The product is RoHS compliant and made under ISO 9001 quality management, and third-party inspection before shipment is welcome so your space-saving ESD circulation PCB rack matches the specification you approved.
