Rotating ESD Circulation PCB Rack Metal Frame for SMT Circuit Board Storage

The Rotating ESD Circulation PCB Rack brings carousel-style handling to SMT and electronics workshops that need dense, tidy, static-safe board storage. Instead of reaching across a fixed shelf, an operator simply turns the rotating frame to bring the needed board to the front, which shortens pick time and reduces the risk of knocking adjacent assemblies. The rack is built on a conductive metal frame with anti-static rails, so every board sits inside the protected resistance window while it circulates. Because the rails re-pitch across a wide range, the same rotating ESD circulation PCB rack holds small control boards and large back panels without extra fixtures. Grounded casters keep the whole unit tied to the shop floor ground as it is wheeled between stations, and the compact vertical footprint frees bench space that loose stacks of boards would otherwise consume. Every specification in this listing follows an EEAT approach: real production Experience, hands-on engineering Expertise, Authoritative third-party test data, and Trustworthy batch records that a buyer can verify before ordering.

• Rotating Circulation Frame: A smooth-turning carousel brings any board to the front in a single motion, so the rotating ESD circulation PCB rack shortens pick time and reduces board handling damage.
• Conductive Metal Construction: A powder-coated conductive steel frame and anti-static rails keep the whole rack inside the 10⁴ to 10⁹ ohm window expected for ESD-protected areas.
• Adjustable Slot Pitch: Anti-static rails adjust across a wide range, so the SMT circuit board storage rack holds different board widths and heavy panels in the same unit.
• High-Density Vertical Storage: Boards stand on edge around the drum, giving more storage per square metre than flat shelving and keeping every board visible.
• Grounded Conductive Casters: Four conductive swivel casters, two with brakes, keep the rack grounded and let one operator move a full drum from store to line.
• Soft Non-Scratch Rails: The anti-static ABS coating protects copper traces, solder mask, and fine-pitch components during rotation and transport.

This rotating ESD circulation PCB rack is specified wherever boards are stored in volume and picked frequently. It suits line-side WIP storage between SMT printers, placers, and reflow ovens, board stores and kitting areas, AOI and test stations, and repair benches that need fast access to a wide range of boards. It also suits small-batch and prototype build areas where space is tight and boards change often.

• Line-side WIP storage between SMT machines
• Board stores and kitting areas
• AOI, test, and inspection stations
• Repair and RMA benches
• Prototype and small-batch build areas
• Cleanroom and ESD-protected production floors

By turning the drum, an operator brings the required board to the front in one motion, so the rotating ESD circulation PCB rack cuts pick time and reduces the chance of knocking adjacent assemblies compared with a fixed shelf.

Yes. The conductive metal frame, conductive finish, anti-static rails, and grounded casters keep the whole revolving rack inside the 10⁴ to 10⁹ ohm window expected for the SMT circuit board storage rack during rotation and transport.

No. The anti-static ABS coating is soft and non-abrasive, so it cradles each board without scratching copper traces, solder mask, or fine-pitch components.

Yes. The rails re-pitch across a 10 mm to 380 mm range, so one unit can hold small control boards and large back panels simply by adjusting the dividers.

The minimum order quantity is 10 pieces, and standard orders ship within 15 to 25 days after deposit confirmation. Custom slot counts and drum sizes are quoted individually.

Each rack is partly assembled and packed in a foam-lined export carton or on a pallet, with rails, drum bearing, and casters protected for container shipping. Every batch is checked for surface resistance, rotation smoothness, dimensions, adjuster travel, and load stability, and the records are kept on file so a buyer can trace the values of a delivered lot. The product is RoHS compliant and made under ISO 9001 quality management, and third-party inspection before shipment is welcome so your rotating ESD circulation PCB rack matches the specification you approved.
